VM3011-U1 PIEZOELECTRIC MEMS MICROPHONE - MIKROFON | MIC
0,00 TL +KDV
Kategori
Marka
Stok Kodu
K000581
Piyasa Fiyatı
gizle
Fiyat
0,00 USD + KDV
Elektromekanik Komponent | Ses Ürünleri | Mikrofon Çeşitleri
VM3011-U1 PIEZOELECTRIC MEMS MICROPHONE
PUI Audio, Inc. mikrofon AUM-5047L-3-R. 50 Hz ~ 16.0 kHz, Circular, Electret Condenser, -47dB ±4dB, Unidirectional, Analog çıkışlı.
| Özellik | Değer |
|---|---|
| Datasheet | PDF Datasheet indir |
| Mfr Part # | VM3011-U1 |
| Mfr | Vesper Technologies Inc. |
| Description | PIEZOELECTRIC MEMS MICROPHONE |
| Series | - |
| Type | MEMS (Silicon) |
| Output Type | Digital, PDM |
| Direction | Omnidirectional |
| Frequency Range | 100 Hz ~ 10.0 kHz |
| Sensitivity | -26dB ±1dB @ 94dB SPL |
| S/N Ratio | 64dB |
| Impedance | - |
| Voltage - Rated | 1.8 V |
| Voltage Range | 1.6 V ~ 3.6 V |
| Current - Supply | 725 µA |
| Port Location | Bottom |
| Ratings | - |
| Termination | Solder Pads |
| Size / Dimension | 0.148" L x 0.116" W (3.76mm x 2.95mm) |
| Height (Max) | 0.055" (1.40mm) |
| Shape | Rectangular |
