CPT-407-105-L60 TRANSDUCER PIEZO 14V 35.5MM FLNG - ALARM, BUZZER, SIREN
0,00 TL +KDV
Elektromekanik Komponent | Ses Ürünleri | Alarm, Buzzer ve Siren Çeşitleri
CPT-407-105-L60 TRANSDUCER PIEZO 14V 35.5MM FLNG
| Özellik | Değer |
|---|---|
| Datasheet | PDF Datasheet indir |
| Mfr Part # | CPT-407-105-L60 |
| Mfr | CUI Devices |
| Description | TRANSDUCER PIEZO 14V 35.5MM FLNG |
| Series | CPT |
| Driver Circuitry | Transducer, Externally Driven |
| Input Type | DC |
| Voltage - Rated | 14 V |
| Voltage Range | 6 ~ 16V |
| Frequency | 3.2kHz |
| Technology | Piezo |
| Operating Mode | Single Tone |
| Duration | - |
| Sound Pressure Level (SPL) | 105dB @ 14V, 30cm |
| Current - Supply | 45mA |
| Port Location | Side |
| Operating Temperature | -30°C ~ 85°C |
| Approval Agency | - |
| Ratings | - |
| Ingress Protection | - |
| Mounting Type | Panel Mount, Flange |
| Termination | Wire Leads with Connector |
| Size / Dimension | 1.398" Dia (35.50mm) |
| Height - Seated (Max) | 0.281" (7.15mm) |
