ADMP404ACEZ-RL OMNIDIRECTIONAL MICROPHONE W/BOT - MIKROFON | MIC
0,00 TL +KDV
Kategori
Marka
Stok Kodu
K000654
Piyasa Fiyatı
gizle
Fiyat
0,00 USD + KDV
Elektromekanik Komponent | Ses Ürünleri | Mikrofon Çeşitleri
ADMP404ACEZ-RL OMNIDIRECTIONAL MICROPHONE W/BOT
CUI Devices mikrofon CMEJ-0733-36-L050. 100 Hz ~ 10.0 kHz, Circular, Electret Condenser, -36dB ±2dB @ 94dB SPL, Omnidirectional, Analog çıkışlı.
| Özellik | Değer |
|---|---|
| Datasheet | PDF Datasheet indir |
| Mfr Part # | ADMP404ACEZ-RL |
| Mfr | Analog Devices Inc. |
| Description | OMNIDIRECTIONAL MICROPHONE W/BOT |
| Series | ADMP404 |
| Type | MEMS (Silicon) |
| Output Type | Analog |
| Direction | Omnidirectional |
| Frequency Range | 100 Hz ~ 15.0 kHz |
| Sensitivity | -38dB ±3dB @ 94dB SPL |
| S/N Ratio | 62dB |
| Impedance | 200 Ohms |
| Voltage - Rated | - |
| Voltage Range | 1.5 V ~ 3.3 V |
| Current - Supply | 250 µA |
| Port Location | Bottom |
| Ratings | - |
| Termination | Solder Pads |
| Size / Dimension | 0.132" L x 0.098" W (3.35mm x 2.50mm) |
| Height (Max) | 0.039" (0.98mm) |
| Shape | Rectangular |
